SUS316L Glucose Rotary Spray Dryer Protein Dryer Spray Drying In Food Industry 100kg/H

Name: SUS316L Glucose Rotary Spray Dryer Protein Dryer Spray Drying In Food Industry 100kgH
Brand: Shinma
Price: 13 USD

Quality SUS316L Glucose Rotary Spray Dryer Protein Dryer Spray Drying In Food Industry 100kg/H for sale

Place of Origin : Jiangsu, China

Brand Name : Shinma

Certification : ISO9001,ISO14001, CE

Packaging Details : As per customer's requirement

Supply Ability : 20 Set/Sets per Year

Price : $13,000.00 - $200,000.00/sets

Type : Spray Drying Equipment

Application : Medicine Processing, Chemicals Processing, Food Processing

Condition : New

Voltage : 220V-450V

Power : Accroding to model

Dimension(L*W*H) : Accroding to model

Key Selling Points : Automatic

Warranty : 1 Year

Weight (KG) : 12000

Applicable Industries : Manufacturing Plant, Food & Beverage Factory, Farms

Showroom Location : None

Marketing Type : Other

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Core Components : Bearing, Pump, Gear, Motor, Gearbox, PLC, Engine

Evaporation Capacity(kg/h) : 100

Heating Method : Steam Heating

Material : SUS304, SUS304L, SUS316, SUS316L, Other

heating source : electricity ,Steam +electricity ,gas ,fuel ,hot air furnace

After-sales Service Provided : Online support, Video technical support, Free spare parts, Field installation, commissioning and training

After Warranty Service : Video technical support, Online support, Spare parts

Local Service Location : None

Port : Shanghai

Contact Now

glucose spray dryer drying equipment price

LPG-100 glucose spray dryer drying equipment price

After fresh air is filtered and heated, it enters into the air distributor which on the top of the drier. The hot air in spiral form equably enters into the drying room.When liquid raw material are passed through the high-speed centrifugal sprayer on the top of the tower, it will be rotated and sprayed into the extreme slim mist liquid beads.

Raw material can be dried to the final products instantly while it contact with the heatedair.Finished products are discharged continuously from bottom of the drying tower and cyclones segregator. Wasted air is discharged from blower.

1, High speed of drying. After the spraying of he material liquid, the surface area of the material will be increased greatly. In the hot-air flow, 95%-98% of water can be evaporated at a moment. The time of completing the drying needs only several seconds.

2, It is especially suitable for drying the heat sensitive materials. It’s final products own the good uniformity, mobility, dissolving capacity. And the final products are high in purity and good in quality.

PRODUCT SPECIFICATIONS

No	Item	Data
1	moisture evaporation amount	100kg/h
2	operation temputure	input air≤350℃,output air 80-100℃
3	Tower outer diameter / tower net height	2.7m/6m
4	Atomizer speed	18000r.p.m
5	Atomization type	Centrifugal atomization
6	Heating source	steam+electricity
7	Product collection method	two cyclones

SUS316L Glucose Rotary Spray Dryer Protein Dryer Spray Drying In Food Industry 100kg/H

Other model technical parameters

Component system

Sketch of Flow Chart
